TEFLON Wire - Spiral Cable Manufacturer
MANLON - MPG - Multi core - Coiled Cable
Manlon Polymers manufactures MPG Coiled Cables for various CNC machines, sensor units and remote controls. We make use of PTFE (TEFLON) wires to give cables extra quality.
MANLON spiral cables with TEFLON insulated wire are light in weight and are designed to withstand harsh industrial surroundings.
Our manufacturing range: up to 25-Core & up to 10 meter expandable Length
 |
TEFLON or PTFE is chemically known as Polytetrafluoroethylene. This is an extremely remarkable and beneficial material and used across several industries.
Benfits of PTFE insulated Wire:
- Provides moisture and heat resistance among other several advantages.
- Gives effective thermal and electrical insulation.
- High performance alternative to standard polyethylene insulation.
- Resistant to fungus and mould growth.
- Non-toxic and bio-compatible.
A PTFE wire is of less O.D. for the same current carrying capacity of PVC Insulated wires. This helps save space to facilitate more no. of insulated wires
in the same size of conduit.
| Wire Size, Sq mm | Current Rating, Amp; PTFE | Current Rating, Amp; PVC |
| 0.15 | 4 | 1.3 |
| 0.25 | 6 | 2 |
| 0.50 | 8 | 4 |
| 1.0 | 15 | 12 |
| 1.5 | 21 | 16 |
| 2.5 | 27 | 22 |
We are capable to offer a wide range of Spiral Cables to various type of industries including thermal power plants, Mobile Generators, Road eqiupments, Earthing applications etc.
